COB PRO Series
Product code:
Features
- COB based LED Strips having power rating of 20 & 30Watts/meter and luminous efficacy of up to 95 lumens/Watt
- This family of COB Strip having FPC (flexible printed circuit) with 3oz layered copper foil for enhanced durability and efficient heat dissipation
- High positioning, high reliability, ultra-thin appearance, and super flexible bending
- Adopting an exclusively designed protective structure, with excellent bending resistance, strong reliability, and stable quality
- 150° beam angle ensures uniform and optimal light distribution
- Colour consistency: SDCM (MacAdam) <4
- 24V DC system designed for stable, flicker-free operation and improved performance
- Colour rendering index (CRI): >90
- LED lifetime: 50,000 hours (L70 @ 25°C)
- Operating ambient temperature: -20°C to +45°C
- IP rating: IP20, IP65 & IP67
- Supplied in a standard 3-meter reel packaging
| Product Code | Wattage | Dimension (mm) |
|---|---|---|
| GL62C-COB | 20W/M | L3000*W15*H2mm |
| GL62C-COB | 30W/M | L3000*W30*H2mm |
Optional:
- DIM : 1-10V Dimming
- DA : Dali Dimmable
- CA : Casambi
Ordering Guide:
- GL62C-COB-20-940-IP20-DA
Application:
Clean the environment part to be attached with a cloth, as shown in Figure 1, and then tear off the 3M tape on the back of the light belt, and finally stick the light belt on the clean place.
